Trusyou Implant System Clinical Cases Phase 2

Patient information:

History of current illness: The patient has been missing teeth for more than a year and requires restoration.

Past history: The patient reported previous physical examinations and found no history of high blood pressure, heart disease, diabetes, or infectious diseases such as hepatitis and tuberculosis or close contact history. There was no history of major trauma or surgery, and no history of blood transfusion. There was no history of drug or food allergies, vaccinations were carried out locally, and no obvious abnormalities were found in the rest of the system review. No history of smoking or drinking.

Physical examination: Height: 1.65 m Weight: 63.0 KG

T: 36.7℃ P: 82 times/min R: 22 times/min

BP: 115/75 mmHg

Imaging examination: no obvious absorption of alveolar bone

Example 2 of short-term clinical comparison of Excellent implants applied to dentition defects

patient information：

Name: Gao Moumou
Age:34
Gender:Female
Marriage:married
Contributor: myself
Record date:2012/11/04

Main complaint: missing teeth, affecting chewing, requiring restoration.

History of current illness: The patient has been missing teeth for more than a year and requires restoration.

Past history: The patient reported previous physical examinations and found no history of high blood pressure, heart disease, diabetes, hepatitis, tuberculosis and other infectious diseases and no history of close contact with them. There was no history of major trauma or surgery, and no history of blood transfusion. There was no history of drug or food allergies, vaccinations were carried out locally, and no obvious abnormalities were found in the rest of the system review. No history of smoking or drinking.

Physical examination:
Height: 1.65 m
Weight: 63.0KG
T: 36.7℃ P: 82 times/min
R: 22 times/min
BP:115/75mmHg
Condition of opposing jaw teeth: normal
Mesial and distal adjacent teeth: 36 missing
Imaging examination: no obvious alveolar bone absorption

Diagnosis: 36 missing
Treatment plan: 36 implants of Truysou implants

Operation situation：

BL.RC4112 implant placement
Surgery date: 2012/11/13

Intraoperative observations:
Vital signs: T: 36.6℃, P: 084 times/min, R: 20 times/min, BP: 120/75 mmHg
Type of disinfectant: iodophor
Anesthesia method: infiltration anesthesia
Incision method: I-shaped incision

Postoperative records:
Implantation sites: 36
Implantation site bone quality: Class III bone
Evaluation of bone mass at the implant site: no alveolar bone absorption
Implant model: BL.RC4112, Ф4.1, L=12
Healing cap: BL.HA.RC6020, Ф6.0, H=2
Whether to use bone grafting: No
Implantation method: non-embedded
Implant stability: good
Suture condition: interrupted suture
Postoperative medication: Cefadroxil 0.25g times/2/day, 3 days
Imaging examination: The direction and position of the 36 implants are good.
Postoperative doctor's instructions: pay attention to oral hygiene maintenance, follow up with follow-up consultations on time, and follow up if any discomfort occurs.

Postoperative imaging：

The implant is in good three-dimensional position
Sufficient bite clearance
36 first thread bone height 2.6mm
Initial stability>35N

Repair image:
The implant is in good three-dimensional position
Sufficient bite clearance
Restorative adhesive tape
36 first thread bone height 2.6mm
The abutment has good stability

Images five years after restoration：
The implant is in good three-dimensional position
Sufficient bite clearance
Close fitting of the edges of the restoration
36 first thread bone height 2.6mm
The abutment has good stability

Author introduction：
Tong Xin
Department: Department of Oral Implantology, Affiliated Stomatological Hospital of Nanjing University School of Medicine Position: Chief Physician, Associate Professor, Master Tutor, Director of the Department of Oral Implantology
