Trusyou Implant System Clinical Cases Phase 3

Patient information:

History of current illness: The patient has been missing his right lower teeth for several years, and now 5 and 6 of the upper left teeth have fallen off, which affects eating, so he came to our hospital for repair.

Past history: The patient reported previous physical examinations and found no history of high blood pressure, heart disease, diabetes, or infectious diseases such as hepatitis and tuberculosis or close contact history. There was no history of major trauma or surgery, and no history of blood transfusion. There was no history of drug or food allergies, vaccinations were carried out locally, and no obvious abnormalities were found in the rest of the system review. Smoking history: 10-15 cigarettes/day, a small amount of drinking.

Physical examination: Height: 1.71 m Weight: 67.0 KG

T: 36.7℃ P: 78 times/min R: 18 times/min

BP: 130/85 mmHg

Opposite jaw teeth: 15 25 26 missing

Mesial and distal adjacent teeth: 37 46 47 missing

Imaging examination: mandibular central incisors were congenitally missing, 46 to 47 were slightly vertically resorbed, and 37 were moderately resorbed.

Example 3 of short-term clinical comparison of Excellent implants applied to dentition defects

patient information:

Name: Zheng
Gender: Male
Contributor: myself
Age:50
Marriage:married
Record date:2012/08/21

Chief complaint: The left tooth is missing and requires restoration.

History of current illness: The patient has been missing his right lower teeth for several years, and now the upper left 56 teeth have fallen off, which affects eating, so he came to our hospital for repair.

Past history: The patient reported previous physical examinations and found no history of high blood pressure, heart disease, diabetes, hepatitis, tuberculosis and other infectious diseases and no history of close contact with them. There was no history of major trauma or surgery and no history of blood transfusion. There was no history of drug or food allergies, vaccinations were carried out locally, and no obvious abnormalities were found in the rest of the system review. Smoking history: 10 to 15 cigarettes/day, a small amount of alcohol.

Physical examination:
Height: 1.71m, weight: 67.0KG, T: 36.7℃, P: 78 times/min, R: 18 times/min, BP: 130/85 mmHg
Opposing teeth: 15 25 26 missing mesiodistally
Condition of adjacent teeth: 37 46 47 missing
Imaging examination: mandibular central incisors were congenitally missing, 4647 had mild vertical resorption, and 37 had moderate resorption.

Diagnosis: 37 46 47 missing

Treatment plan: Implantation treatment at 37, 46 and 47 sites

Preoperative imaging:

Many missing teeth
Oral hygiene is average
Different degrees of alveolar bone resorption

Operation situation：

37 46 47 site BL.RC4110
Implant implant surgery date: 2012/09/27

Intraoperative observations:
Vital signs: T: 36.7℃, P: 082 times/min, R: 19 times/min, BP: 120/80 mmHg
Type of disinfectant: iodophor
Anesthesia method: infiltration anesthesia
Incision method: I-shaped incision

Postoperative records:
Implantation site: 36, 46, 47
Implantation site bone quality: Class III bone
Bone mass evaluation at the implantation site: 46, 47 mild vertical absorption, 37 moderate absorption Implant model:
37 Excellence series implants, BL.RC4110, Ф4.1, L=10
37 healing cap, BL.HARC6020, Ф6.0, H=2
46 Excellence Series Implant, BL.RC4110, Ф4.1, L=10
46 healing cap, BL.HA.RC6020, Ф6.0, H=2
47 Excellence Series Implants, BL.RC4110, Ф4.1, L=10
47 Healing cap, BL.HA.RC6020, Ф6.0, H=2
Whether to use bone grafting: No
Implantation method: non-embedded
Implant stability: good
Suture condition: interrupted suture
Postoperative medication: Cefadroxil 0.25g times/2/day, 3 days
Imaging examination: The implant placement direction and position are good
Postoperative doctor's instructions: pay attention to oral hygiene maintenance, follow up with follow-up consultations on time, and follow up if any discomfort occurs.

Postoperative imaging：

The implant is in good three-dimensional position
Sufficient bite clearance
37 first thread bone height 2.6mm
46 first thread bone height 2.2mm
47 first thread bone height 2.2mm
Initial stability>35N

Repair one year after planting:

The implant is in good three-dimensional position
Sufficient bite clearance
37 Excellence Series Adhesive Abutments, BL.TA.5NC3520, 3.5H=5
37 Excellence Series Adhesive Abutments, BL.TA.5NC3520, 3.5H=5
37 Excellence Series Adhesive Abutments, BL.TA.5NC3520, 3.5H=5
37 The height of the first thread bone is 2.2mm
46 The first threaded bone height is 1.8mm
47 The first threaded bone height is 1.8mm
Close fitting of the crown edge of the restoration
No abnormalities around the implant

Images five years after restoration：

The implant is in good three-dimensional position
37 The height of the first thread bone is 2.2mm
46 First thread bone height 2.0mm
47 The first threaded bone height is 1.8mm
Close fitting of the crown edge of the restoration
No abnormalities around the implant

Images five years after restoration：

Author introduction：
Tong Xin
Department: Department of Oral Implantology, Affiliated Stomatological Hospital of Nanjing University School of Medicine Position: Chief Physician, Associate Professor, Master Tutor, Director of the Department of Oral Implantology
